Europe West | Italy
Wind Tre Italy
FDD uplink (703 - 733 MHz )
FDD downlink (758 - 788 MHz )
FDD uplink (832 - 862 MHz )
FDD downlink (791 - 821 MHz )
FDD uplink (880 - 915 MHz )
FDD downlink (925 - 960 MHz )
SDL (1432 - 1517 MHz )
FDD uplink (1710 - 1785 MHz )
FDD downlink (1805 - 1880 MHz )
(1900 - 1920 MHz )
FDD uplink (1920 - 1980 MHz )
FDD downlink (2110 - 2170 MHz )
(2570 - 2620 MHz )
FDD uplink (2500 - 2570 MHz )
FDD downlink (2620 - 2690 MHz )
(3400 - 3800 MHz )
(24250 - 29500 MHz )
Layer (MHz) | 3GPP band | FDD / TDD / SDL | Uplink Start (MHz) | Uplink End (MHz) | Downlink Start (MHz) | Downlink End (MHz) | Total (MHz) | Nationwide / Regional | Region |
---|---|---|---|---|---|---|---|---|---|
800 | n20 | FDD | 832.0 | 842.0 | 791.0 | 801.0 | 10.0 | Nationwide | - |
900 | n8 | FDD | 905.2 | 914.8 | 950.2 | 959.8 | 9.6 | Nationwide | - |
1800 | n3 | FDD | 1745.0 | 1765.0 | 1840.0 | 1860.0 | 20.0 | Nationwide | - |
1900 | n33 | TDD | 1900.0 | 1905.0 | 1900.0 | 1905.0 | 5.0 | Nationwide | - |
1900 | n33 | TDD | 1915.0 | 1920.0 | 1915.0 | 1920.0 | 5.0 | Nationwide | - |
2100 | n1 | FDD | 1920.0 | 1940.0 | 2110.0 | 2130.0 | 20.0 | Nationwide | - |
2600 | n38 | TDD | 2570.0 | 2585.0 | 2570.0 | 2585.0 | 15.0 | Nationwide | - |
2600 | n38 | TDD | 2585.0 | 2600.0 | 2585.0 | 2600.0 | 15.0 | Nationwide | - |
2600 | n7 | FDD | 2550.0 | 2570.0 | 2670.0 | 2690.0 | 20.0 | Nationwide | - |
3500 | n78 | TDD | 3600.0 | 3620.0 | 3600.0 | 3620.0 | 20.0 | Nationwide | - |
26000 | n257. n258. n261 | TDD | 25053.0 | 25109.0 | 25053.0 | 25109.0 | 56.0 | Regional | Regions Abruzzo. Basilicata. Bolzano. Campania. Calabria. Emilia Romagna. Friuli Venezia Giulia. Lazio. Liguria. Lombardia. Marche. Molise. Piemonte. Puglia. Sardegna. Sicilia. Toscana. Trento. Umbria. Veneto and Valle dAosta |
26000 | n257. n258. n261 | TDD | 26500.0 | 26700.0 | 26500.0 | 26700.0 | 200.0 | Nationwide | - |
